Fixed single surface mount resistor - CRE series

  • Description
  • Details
    • Commodity name: Fixed single surface mount resistor - CRE series
    • Commodity ID: 1122612275664539648

    This is Bourns' CRE2512-FZ-R007E-3 fixed single surface mount resistor. The resistance value of this product is 7m ohms. This reliable component is rated at 3 W. It is also equipped with current sensing technology. Its temperature coefficient is ±75 ppm/°C. This product will be shipped in tape and reel packaging for quick installation and safe delivery. It has a tolerance of 1%. This product measures 6.45 mm long, 0.7 mm high and 3.35 mm deep. The operating temperature of the part is -55 to 170 °C. The device adopts thick film technology.

    Product Technical Specifications

    EU RoHS compliance
    ECCN (USA) EAR99
    Part status Positive
    High temperature superconductivity 8533.21.00.20
    Car yes
    PPAP yes
    Resistance value (ohms) 7M
    tolerance 1%
    Current sensing yes
    Rated Power (W) 3 pcs
    technology Metal alloys
    Minimum Operating Temperature (°C) -55
    Maximum Operating Temperature (°C) 170
    Temperature coefficient (ppm/°C) ±50
    Temperature range at derating power (°C) 70 to 170
    Fail-safe fusing resistors No
    Surge proof No
    Resistant to sulfurization No
    Case size 2512
    Termination method Cushioned
    Number of terminals 2 pcs
    pack Tapes and reels
    Packaging type Placement machine
    Package shape rectangle
    Packaging/Case 2512
    Product Length (mm) 6.4
    Product depth (mm) 3.2
    Product Height(mm) 0.7
    Installation Surface mount


    CRE2512-FZ-R007E-3 in stock!
    For more parameters, please see < details in the >!
