features size 0603 to 2512 Thick Film Chips0805 to 1206 Metal Foil Chips0805 to 2512 Metal Strip Chips
: 2512 to 5931 EB Welding Splitters, 6918 to 8536 Metric EB Welding Splitters
Rated power at 70 °C 0.1 to 50 watts Resistance range 25 microohms to 9.1 ohms Resistance tolerance ±0.5%、±1%、±5% Temperature coefficient ±50 至 ±200 ppm/°C Operating temperature range –55 to +155/+170 °C
Available featuresRoHS
compliant*Suitable
for most types of welding processesEB
welding shunts
comply with AEC-Q200
and have very high power
resistance
Excellent long-term stability
, low inductance value
, low thermal electromotive force
, low TCR
, available in four terminal designs
: bare copper and tinned terminals
are sulfur resistant
Application
Telecom specifications in the consumer
industry have resistance ranges from 0.2 to 5 milliohms
Tolerance 1% / 5%
Temperature Coefficient ±50 ppm
Power (W) 2 to 12 watts
Introduction/Package Styles Surface Mount
Materials Metal Elements
CSS2H-3920R-L500F CSS2H-3920R-L300F
In stock!
For more parameters, please see < details in the >! -
