BVR
High current applications for the automotive market
Frequency converters
Power modules
Category:
Message
- Description
- Details
-
Features
Constant current up to 245 A (0.2 mOhm)Power rating up to 12 WFour terminal-configurationExcellent long-term stabilityIdeal suited for mounting on DBC / IMS substrateMax. solder temperature up to 350 °C / 30 secAEC-Q200 qualified
Advantages / Features
Copper joint
It can withstand a welding high temperature of +350℃ for 30 seconds
High power
Excellent long-term stability
Technical parameter
Resistance range: 0.2 / 0.3 / 0.5 /0.7 / 1 / 2 / 3 mOhm
Tolerance:1 / 5%
Temperature coefficient：﹤20ppm/k（20℃-60℃）
Applicable temperature range：-55℃至+170℃
Power rating :最大5W
Internal heat resistance (Rthi)：最小10K/W
Inductance:﹤3nH
Stability (at rated power) deviation after 2000h：﹤0.5% after 2000h(TK＝100℃)
TK = Terminal temperature：﹤1.0% after 2000h(TK＝130℃)
BVR-M-R001-1.0
BVR-Z-R0002-1.0
BVR-Z-R0005-1.0 有货！
更多参数请见<详情介绍>内！ -
